USPE Low-Profile 4-Tier Morgue Cadaver Rack

Low-Profile 4-Tier Morgue Cadaver Rack, USPE-CR-LP4, reference configuration; standard-height reference, not the proposed low-profile geometry
Low-Profile 4-Tier Morgue Cadaver Rack, USPE-CR-LP4, reference configuration; standard-height reference, not the proposed low-profile geometry (1 / 1)

USPE equipment

USPE Low-Profile 4-Tier Morgue Cadaver Rack

Model: USPE-CR-LP4-SL-78X23

Quote only

Request a quote for your selected model and configuration.

Request a quote

Production lead time is model- and configuration-specific. Confirm the current schedule in your written quote before ordering.

1-888-792-9315
140 Kwick Way Lane, Building 7, Johnson City, TN 37615

Product details

Available in stainless steel. Quote-only equipment from U.S. Pathology Equipment.

A proposed low-profile four-tier cadaver rack for institutional rooms with restricted height. Submit the actual tray and body-clearance requirements before treating four positions as usable capacity.

Quote only · Model USPE-CR-LP4

Configuration overview

  • Four-tier low-profile configuration request
  • Stationary side-load or end-load layout review
  • Reduced overall height must be checked against usable tier clearance
  • Standard-height rack photo shown as a reference only

Specifications and approval requirements

Model USPE-CR-LP4
Design status Proposed configuration; not an approved production specification
Target overall height 60 inches, proposed planning target only
Target footprint 83 × 29 inches, proposed planning target only
Tier spacing To be resolved against tray depth and required body clearance
Load rating Not established; written engineering confirmation required
Trays / lift Separate compatibility review

Options to request

Selections are requests, not confirmed included equipment. Final specifications and compatibility require written approval.

  • Side-loading configuration review
  • End-loading configuration review
  • 27-inch tray-format review
  • Custom tray-width review
  • Required body-clearance review
  • Lift low-position review
  • Leveling feet / anchorage review
  • Matching tray quotation

Frequently asked questions

Is this a released production model?

No. It is a quote-stage planning configuration. Final height, tier spacing, capacity and stability require approval.

Does the reference photo show the low-profile rack?

No. It shows a standard four-tier rack. The proposed low-profile arrangement is identified separately in the planning sketch.

Can four positions fit under every low ceiling?

No. The usable body clearance and lift approach must be checked for each position. A nominal tier count is not a verified usable capacity.

Related equipment

Forensic pathology equipment · Vault morgue coolers · Laboratory casework

Custom configurations and coordinated RFQs

Custom configurations are available across our equipment and rack lines. Request custom overall dimensions, tray widths, tier count or spacing, bay count, roller arrangement, casters or leveling feet, work surfaces, drainage, utilities and room integration as applicable. Your written quote and approved drawings define the build, materials, load rating and confirmed compatibility; selecting an option is not engineering approval.

Stainless tray and matching rack selections

Tray selection Outside tray dimensions Tray gauge / published load Rack request
23-inch width 78 L × 23 W × 2.75 H inches 18 gauge / 300 lb Rack sized and rated for this exact tray; final drawing required
27-inch width 78 L × 27 W × 2.75 H inches 16 gauge / 400 lb Rack sized and rated for this exact tray; final drawing required
30-inch width 78 L × 30 W × 2.75 H inches 14 gauge / 500 lb Rack sized and rated for this exact tray; final drawing required

Fit approval is required, not implied by nominal width. The quotation must identify the exact tray outside dimensions, usable rack opening, rail/roller support spacing, tray stops and latch engagement, approved tray overhang, tier spacing, loaded transfer height, and per-tier and total rack ratings including tray weight. Confirm cooler doorway, aisle, turning and lift clearances on the approval drawing. A wider tray requires a correctly widened rack, not placement in a narrower standard rack. Rack photos illustrate the equipment format, not every selected width.
