Apply with TimePayment (opens in a new tab)3-Body Vault Morgue Cooler
American Mortuary Coolers
Sale
Model: 1070-3MBS · 2026 Model
Regular price
$19,795.05
List price
$24,991.23
Sale price
$19,795.05
Unit price
per
Estimated from
3-Body Vault Morgue Cooler
$19795.05
Apply with TimePayment (opens in a new tab)
Apply for financing
Equipment estimate only. Subject to lender approval and terms. Tax and delivery extra.
Zelle®
ACH
Shipping calculated at checkout.
- 3-body side-load vault morgue cooler
- Model 1070-3MBS, one door per chamber
- Stainless steel slide-out trays
- 96 x 42 1/4 x 117 1/2 in overall
- 304 stainless steel interior
Purchase terms & policies Shipping, returns, warranty and financing disclosures
Key details
- 3 individually accessed chambers, one door per chamber
- Slide-out tray rails in every chamber; body trays sold separately
- MortuaryGlide™ full-extension rails
- 304 stainless steel interior, 4″ urethane-core insulated panels
- Refrigeration: Self-contained, 208–230V, single-phase
Product information
Product details & specifications
Product details
Built in Tennessee by American Mortuary Coolers, this 3 body vault morgue cooler has one door and one slide-out tray rail set per chamber and starts at $19,795.05.
A 3-body vault morgue cooler provides a separate refrigerated chamber and access door for each body; this USA-made U.S. Pathology Equipment model starts at $19,795.05 with slide-out tray rails and 208–230V refrigeration.
Individual chamber doors let staff access one storage position without opening a shared cabinet. Body trays are sold separately. Compare vault morgue cooler capacities and layouts and confirm tray compatibility, retrieval height and installation clearances.
NSF and UL marked refrigeration and electrical components. Made in the USA by U.S. Pathology Equipment.
Form USPE-SS-1070-3MBS · Rev. A · PDF
USPE 1070-3MBS 3-Body Vault Morgue Cooler Sign-Off Drawing & Site Requirements
Front, side and plan views with dimensions, refrigeration sizing, site and power requirements, loading height and purchase terms. Sign and return before the vault is built.
Download PDFThe 3-Body Vault Morgue Cooler (Model 1070-3MBS) holds 3 bodies in individually accessed chambers, each with its own door and slide-out tray rails (body trays sold separately).
At a glance
- 3 individually accessed chambers, one door per chamber
- Slide-out tray rails in every chamber; body trays sold separately
- MortuaryGlide™ full-extension rails
- 304 stainless steel interior, 4″ urethane-core insulated panels
- Refrigeration: Self-contained, 208–230V, single-phase
- 34–40°F body holding
Options
- Refrigeration Upsize: Standard is sized for a climate-controlled indoor room. Choose Level 1, 2 or 3 Extreme for warmer rooms (table below).
- Casters: extra heavy-duty casters, +$495.
- Body trays and lifts: sold separately; add them below.
Standard design features
- Self-contained condensing unit. The compressor, condenser and evaporator come as one factory-packaged unit mounted on the cabinet, so no refrigeration lines are run on site.
- Digital thermometer and temperature controller. A digital display shows the box temperature at a glance, and the controller holds the setpoint you choose for body holding.
Door seal and refrigeration
- Magnetic gasketed door seal. Each chamber door closes against a magnetic gasket that seals the whole door edge, which keeps cold air in and holds 34–40°F after the door is opened.
- Energy-compliant refrigeration. The self-contained refrigeration system uses A2L refrigerant and meets current DOE/EPA efficiency rules.
Room temperature and refrigeration sizing
| Room conditions at the vault | Refrigeration | Upgrade |
|---|---|---|
| Climate-controlled prep room, 65–75°F, normal door use | Standard | Included |
| Warm room that regularly reaches 80°F | Level 1 | +$4,044.71 |
| Hot room up to 90°F, or heavy daily door traffic | Level 2 | +$4,449.18 |
| Room up to 100°F, high humidity, or nearby heat-producing equipment | Level 3 Extreme | +$4,853.65 |
Install indoors only. Keep the condensing unit’s intake and discharge clear. See Ambient Temperature & Refrigeration Sizing (AT-1.0) and Ventilation & Clearance (VC-1.1).
Specifications
| Model number | 1070-3MBS |
|---|---|
| Capacity | 3 cadavers, individual chamber access |
| Overall size | 96″ W × 42 1/4″ D × 117 1/2″ H with condensing unit |
| Cabinet height | 97 1/2″ (condensing unit adds 20″) |
| Chamber opening | 84″ W × 21″ H |
| Bottom tray height | 13″ from the floor |
| Door configuration | 3 doors, one per chamber |
| Loading | Side-load; trays slide out through the 96″ front |
| Tray system | Tray rails included; body trays sold separately (23″, 27″ or 30″) |
| Interior construction | 304 stainless steel |
| Cabinet | Modular insulated panels, 4″ urethane core |
| Refrigeration | Self-contained |
| Operating range | 34–40°F body holding |
| Voltage | 208–230V, single-phase |
| Certifications | NSF, UL, ASTM E84 Class A, DOE/EPA EISA 2007, Prop 65 |
| Country of origin | United States, Johnson City, Tennessee |
| Manufacturer | American Mortuary Coolers |
| Warranty | Warranty Policy (WR-1.0) |
Loading height notice
The bottom tray sits 13″ from the floor. The TITAN 1030-LPL low-profile lift (13″ to 69″) is the only AME lift that reaches it. The H1000-M manual scissor lift (from 20 1/2″) and the G1 lift do not meet the minimum loading height for this vault. Confirm lift compatibility before ordering. We are not responsible for lift selection or ordering errors. See the Returns & Cancellations Policy (RC-1.1) and Terms of Purchase (TC-1.7).
Before you order
- Ceiling height of at least 117 1/2″ to the top of the condensing unit, plus the clearance required by VC-1.1.
- Clear aisle in front of the 96″ face so trays can extend fully and the lift can line up square.
- Dedicated 208–230V single-phase circuit sized to the unit nameplate, installed by a licensed electrician.
- Delivery path (doors, halls, elevators) that takes the crated panels.
Delivery and installation
- Ships by freight as an unassembled panel cabinet for on-site assembly. Freight is shown at checkout.
- Unloading equipment and site access are the customer’s responsibility under Freight Carriers & Delivery Terms (FC-1.0). Inspect every crate before signing, per the Freight Damage, Inspection & Refusal Policy.
- Assisted panel installation may be offered as a courtesy within the shipping charge, per AP-1.0. Turnkey delivery and installation is not included; it is available by written quote under TK-1.0.
- Manuals and startup guides: Packaged Refrigeration Manuals.
Trays, lifts and add-ons
- Body trays are not included. Add 23″, 27″ or 30″ stainless steel body trays on this page, up to one per chamber.
- Lifts: the Low Profile Mortuary Lift lowers to 13″ for the bottom chamber. Check the lowest and highest platform heights of any lift against every tray before ordering.
- Extra heavy-duty casters: +$495, selected above.
- Turnkey delivery and installation: not included. Inside delivery, rigging, panel assembly and refrigeration start-up are available by written quote under TK-1.0. Ask before you order.
Custom builds and institutional orders
Model 1070-3MBS is our base model. We build vault coolers to any specification: chamber count and layout, bariatric chambers, opening and tray sizes, hinge side, refrigeration capacity and voltage, and a footprint to fit an existing room. Every custom build is drawn for sign-off before fabrication.
Hospitals, medical examiner and coroner offices, universities, anatomy programs, laboratories and government agencies can send an RFQ or purchase order to po@mymortuarycooler.com. We return a formal quote with the data sheet and sign-off drawing for your bid file. U.S. Pathology Equipment also builds autopsy stations, grossing stations, autopsy and dissection tables, sinks, stainless casework, laboratory refrigerators, morgue carts and racks and lifts.
Purchase terms
Vault coolers are final sale. Vault orders cannot be cancelled under any circumstances once placed.
Each vault is built to order from the signed sign-off drawing and is non-returnable once ordered. The exception terms for other coolers do not apply to vaults. Read the full Returns & Cancellations Policy (RC-1.1), Warranty Policy (WR-1.0) and Terms of Purchase, Return & Chargeback Policy (TC-1.7). Questions: 1-888-792-9315 or cool@mymortuarycooler.com.
Purchase orders accepted.
Frequently asked questions
What temperature does a vault morgue cooler hold?
This vault cooler holds 34–40°F for short-term body holding. Long-term holds and unidentified cases are usually moved to a mortuary freezer. See mortuary cooler vs. morgue freezer.
Are body trays included?
Slide-out tray rails are included in every chamber. Body trays are sold separately in 23″, 27″ and 30″ widths, and you can add as many as you need in any mix. Shop body trays and boards.
What room conditions does the vault cooler need?
Standard refrigeration is sized for a climate-controlled indoor room at 65–75°F with normal door use. Choose Level 1, 2 or 3 Extreme refrigeration for rooms that reach 80°F, 90°F or 100°F, or that see heavy door traffic. Install indoors only, and keep the condensing unit’s intake and discharge clear.
Vault cooler or walk-in: which fits a hospital morgue layout?
A vault cooler gives each body its own chamber and door, so staff open one chamber at a time and keep the rest closed. A walk-in with racks is more flexible for surge and mixed body sizes. Compare layouts in vault-style vs. roller-rack storage and the hospital morgue design guide.
How many chambers does a hospital morgue need?
Plan from peak census and local policy. Published health-facility guidelines range from about 1 refrigerated space per 25 beds to 4 per 100 beds, plus dedicated bariatric and isolation chambers. Use the capacity planning guide to size the bank.
What certifications does it carry?
The refrigeration and electrical components are NSF and UL marked. See the Certifications row in the specifications for the full list.
Can you build a custom vault cooler or lab vault cooler design?
Yes. Send the chamber count, layout, tray widths and room dimensions through our quote builder, and we will return a written quote.
How is shipping charged?
The vault cooler ships by freight, and shipping is calculated at checkout for your delivery address. Purchase orders are accepted.
Ordering 3-Body Vault Morgue Cooler
Review the listed specifications, selected options and included items before ordering. Use the configuration selector for the current price and availability; do not assume that accessories pictured with a product are included unless the listing says so.
Source funeral supplies and mortuary equipment from one supplier, with nationwide shipping. For an equipment package or a multi-location order, request an itemized quote with the selected products, quantities and delivery ZIP codes. Confirm freight and delivery requirements for the equipment you choose.
